Scott Aspect eRIDE 920

Scott Aspect eRIDE 920
Please select options Unavailable


The SCOTT Aspect eRIDE 920 features proven electric assist technology in a comfortable off-road package. With an integrated battery and powered by a 625Wh Bosch drive system, the Aspect eRIDE will give you hours of trail riding energy.

bike frame with labeled dimensions
Bike Sizes:
Small / 900Medium / 900Large / 900X-Large / 900
A. Reach 398.0mm 415.0mm 433.0mm 450.0mm
B. Stack 637.0mm 644.0mm 653.0mm 663.0mm
C. Standover 787.0mm 809.0mm 838.0mm 853.0mm
D. Effective Top Tube 580.0mm 600.0mm 620.0mm 640.0mm
E. Head Tube Angle 67.5 ° 67.5 ° 67.5 ° 67.5 °
F. Head Tube Length 110.0mm 120.0mm 130.0mm 140.0mm
G. Seat Tube Angle 75.2 ° 75.0 ° 74.9 ° 74.7 °
H. Seat Tube Length 400.0mm 440.0mm 480.0mm 520.0mm
I. Bottom Bracket Height 320.0mm 320.0mm 320.0mm 320.0mm
J. Bottom Bracket Drop 57.0mm 57.0mm 57.0mm 57.0mm
L. Trail 90.5mm 97.0mm 97.0mm 97.0mm
M. Wheelbase 1,160.0mm 1,180.0mm 1,202.0mm 1,222.0mm
O. Chainstay Length 480.0mm 480.0mm 480.0mm 480.0mm


Frame Alloy frame tapered headtube E2 custom butted tubing / internal cable routing Bosch Gen4 / integrated removable battery / Boost 148x12mm DO kickstand mount / Range Booster Ready
Fork SR Suntour XCM34 Coil 15x110mm QR axle / Tapered Steerer / Remote Lockout / 120mm travel
Rims Syncros MD30 / 32H / 30mm / Pin Joint / Tubeless ready
Hubs Front: Formula CL-811 / Boost 15x110mm
Rear: Formula CL-148S / Boost 148x12mm
Spokes Stainless Black
Tires Front: Kenda Booster 29x2.6" / 30TPI
Rear: Kenda Booster 29x2.6" / 30TPI
Crankset FSA CK-220 / 165mm
Shifters SRAM SX Eagle Single Click
Rear Derailleur SRAM NX Eagle / 12 Speed
Cassette/Freewheel SRAM PG1210 / 11-50 T
Chain SRAM SX Eagle
Brakes Shimano BR-MT200 Disc
Rotors Front: SM-RT30 CL 180mm / Rear: RT-EM300 CL 180mm
Handlebars Syncros 3.0 720mm / 31.8mm / 9° / 12mm rise
Tape/Grips Syncros Comfort lock-on grips
Stem Syncros 3.0 / 7° / Black
Headset Syncros OE / Tapered 1.5"-1 1/8" semi-integrated OD 50/62mm / ID 44/56mm
Seatpost Syncros 3.0 / 31.6mm
Saddle Syncros ER2.5
Accessories & Extras Bosch light cable pre-installed F&R
Motor Bosch Performance CX EU: 25kmh / INT: 20mph
Battery PowerTube 625Wh
Controller/Display Bosch Purion
Charger 2A Charger

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Black / Large 192820614816 286715010 210000058678
